Description

Application:	Industry, School, Hospital, Lab
Certification:	CE
Type:	Heating Type
Certificate:	CE
Transport Package:	Standard Export Carton
Specification:	CE, SGS, ISO

Customization:	Available \|Customized Request

Product Description

Eletronic temperature regulation mode with characteristics of stepless speed adjustable,up to 450ºC general heating.
Product Description:

Eletronic temperature regulation mode with characteristics of stepless speed adjustable
Main Technical Parameters:

Model		98-I-B
Function	Capacity(ml)	50	100	250	500	1000	2000	3000		5000	10000	20000
	Heating Mode	Surface heat-conduction
	Surface Max. Temp.( ºC)	450ºC
Structure	Heating element	Nichrome wire
	Shell (Insulation Layer)	High quality aluminum silicate cotton
	Heat power (kW)	0.08	0.1	0.15	0.25	0.35	0.45	0.6	0.8		1.2	2.5
Controller	Working Mode	Continuous
Specification	Exterior Size (mm)	¢220×165				¢280×220	¢330×230	¢340×245	¢350×250		¢425×320	¢470×340
	Packing Size (mm)	230×230×195				290×290×300	340×340×350	360×360×300	390×390×310		430×430×350	510×510×380
	Voltage(V)	100~120V or 200~240V						200~240V
	N.W.(Kg)	2.5				5.5	6.5	7.5	8		9.8	16
	G.W. (Kg)	2.8				6	7	8	9.2		12	20
