LW-6020C 60V 20A High Power Programmable DC Power Source Digital Adjustable Cellphone Repairing Power

Features:
1, LCD liquid crystal display, no radiation, no flicker
2, USB interface and RS485 interface, two interfaces, can meet the requirements of a variety of customers on the interface
3, multiple protection devices: overload protection, overvoltage protection, overcurrent protection, over temperature protection
4, can store 6 sets of data

Application Areas:
1. Battery charging.
2. Car DVD, car audio.
3. Product aging, such as resistors, capacitors, relays, DC motors, LEDs, etc.
4. Laboratory, factory, maintenance power supply.
5. Everything else needs DC regulated power supply.

Technical Parameter:
1. Input voltage: AC: 220V ± 10% 50Hz ± 5Hz
(Can be ordered: AC: 110V ± 10% 60Hz ± 5Hz)
2. Voltage output:
Power effect: ≤0.05%+10mv
Load effect: ≤0.1%+10mv
Grain and noise: 10mVrms, 50mVpp
Setting accuracy: ±(0.03% of reading + 10mv)
Set resolution: 10mv
Voltage resolution: 10mV
3. Current output
Power effect: ≤0.05%+10mA
Load effect: ≤0.1%+10mA
Ripple and noise: 10mArms
Setting accuracy: ±(0.03% of reading + 10mA) Setting resolution: 10mA
Current resolution: 10mA

4. Temperature coefficient: ≤300ppm/oC/
5. Reading accuracy: ± (0.1% of reading + 10mV); ± (0.1% of reading + 10mA)
6. Protection: overload protection, overvoltage protection, overcurrent protection, over temperature protection
7. Interface: USB interface, 485 interface
8. Storage output: 6 groups
9. Insulation: between the output terminal and the chassis or other terminals: ≤60VDC
10. Operating environment: indoor use Ambient temperature: 0-40 ° C Relative humidity: ≤ 80%
11. Voltage input: AC220V±10%, 50/60Hz
12. Accessories: One manual, one power cord
13. Size: 380 (D) × 260 (W) × 155 (H) mm
14. Weight: about 12KG
